P Series

Introducing the P Series HeatMaster pellet outdoor wood boiler that will revolutionize the way you heat your home.

Embrace the perfect solution to lower heating bills and smart automation, all while soaking up lasting warmth. This pellet burning furnace makes it a breeze to stay cozy without breaking a sweat.


Featues:



1. Auto ignition
The control system monitors oxygen levels and senses when to fire the auto igniter to keep your boiler running efficiently and effortlessly.



2. Ultra-Efficient Heat Exchanger
Dual sets of vertical heat exchange tubes with spiral turbulators transfer the maximum amount of heat to your water, ensuring every available BTU is used to heat your home or building(s).


3. Easy maintenance
The use of the EZ clean tool, along with the minimal ash produced while burning will keep your Heat exchange tubes clean. This will help maintain optimal efficiency and performance.


4. Expanded Heat storage Capacity
The built-in recirculation pump helps store the maximum amount of heat in the water jacket by keeping the water temperature consistent from top to bottom.


5. Closed cell spray foam insulation
The insulation value is increased by 50% or more by surrounding the tank with seamless, durable and waterproof closed cell spray foam insulation.


6. Cruise control for you Boiler
The actuator motor continuously adjusts the air damper to maintain optimal fuel – to – air ratios for the cleanest, most efficient burn.


7. Limited lifetime warranty
Our in-house team of expert engineers design every aspect of our boilers to achieve maximum performance and longevity in real world applications. That is why we offer our industry leading Lifetime Limited Warranty.



P 4000.webp

$2,000 Tax Credit approved!

P4000
Approx. Heating Space-  4,000 sq. ft.
Max Heat Output-   150,000 BTU/hr
Water Capacity- 87 Gallons
Recommended Fuel-  wood pellets
Bin Hopper Capacity- 240 LBS
Weight- 1200 LBS
Outlets- 1 set of 1” and 1 set 1.5″
Power Supply- 120V 1PH 60HZ
Chimney Size- 6”
Dimensions (L” x W” x H”) 42″ x 67″ x 83″





P7000
Approx. Heating Space-  7,000 sq. ft.
Max Heat Output-   250,000 BTU/hr
Water Capacity- 125 Gallons
Recommended Fuel-  wood pellets
Bin Hopper Capacity- 320 LBS
Weight- 1600 LBS
Outlets- 1 set of 1” and 1 set 1.5″
Power Supply- 120V 1PH 60HZ
Chimney Size- 6”
Dimensions (L” x W” x H”) 49″ x 67″ x 83″
